EL133UF1 is a color, reflective electrophoretic E Ink® Spectra 6 technology display module. It is based on active matrix TFT substrate.
It has 13.3” active area, the display is capable to display full color images depending on the display controller and the associated waveform file it used.
Tabs
Specification
| Size | 13.3 inch |
|---|---|
| Resolution (HxV) | 1600 * 1200 |
| Active Area | 270.40 * 202.80 mm |
| Outline Dimensions | 284.70 * 208.80 mm |
| Dpi | 150 |
| E Ink Film | Spectra 6 |
| Backplane | Glass |
| Total Thickness | 0.848 mm |
| Grey Level | Full color |
| Front Light | - |
| Interface | QSPI |
| Operational temperature range | 0°C ~ + 50°C |
| New nomenclature | ED2208-NCA |
